RS-Aerogel Blanket

RS-Aerogel Blanket : is a flexible, high-efficiency insulation felt composed of nano-silica aerogel integrated into inorganic fibers (such as glass fiber or pre-oxidized fiber). It is recognized as one of the solid materials with the lowest thermal conductivity currently known.

Key Features

Core Technical Structure:

Superior Thermal Insulation: Extremely low thermal conductivity (≈18W/(m·K） at room temp), providing 3-5 times the insulation performance of conventional materials.
Space & Cost Efficiency: Achieves the same insulation effect with minimal thickness, significantly saving installation space and logistics costs.
Excellent Fire & Water Resistance: Meets A1 Class non-combustible standards and features high hydrophobicity, preventing Corrosion Under Insulation (CUI) by blocking moisture penetration.

Product Advantages:

Superior Weather Resistance：Chemically stable with a service life of over 20 years, ensuring no performance degradation over time.
Eco-friendly & Non-toxic：Asbestos-free and free from harmful fibers; friendly to both human health and the environment.
High Compressive Strength：The unique nanoporous structure ensures that its thermal stability remains intact even after compression.

Technical

Standard Dimensions:

Product Model	Roll Length	Width	Thickness	Density
RS-Aerogel Blanket	20m，40m	1500mm	3mm，6mm，10mm，20mm	180kg/m³-220kg/m³

Technical Specifications:

Product Model	Thermal Conductivity	Compressive Strength	Moisture Content	Hydrophobicity	Service Temp	Fire Classification
RS-Aerogel Blanket	≤0.020 W/(m·K)	≥100 kPa	≤0.5%	≥99%	-200℃ to 650℃	A1
